Staff ID:
Brand: NUX
MODEL: LOOPCORESTEREO
NUX Loop Core Stereo Loop Pedal Effects
AED
299
AED
439
Easy Payment Plans
i
Same-day to 2-day delivery
Check availability in store
Please enable your browser location services in order for us to help you get personalized store listing based on your current location. Alternatively, you may proceed to choose store from list or search for your favorite store.
Store finder
Loop Core Stereo
The NUX Loop Core Stereo is our next generation Looper pedal. Featuring a high-definition color LCD display, stereo inputs/outputs, and a MIDI control input; the Loop Core Stereo allows you to create up to 6 hours of music phrases, save them in one of 99 provided memory slots, and play back as stereo loops! Also included are 50 different drum patterns to complete the looping experience. Whether you practice, compose, or play live gigs, you’ll be inspired from the very first loop!
Setup 1
Mono in, mono out.
This is the most common loop pedal setup for guitarists. Plug in a guitar to the A/Mono input on the Loop Core Stereo and connect A/Mono output directly to a guitar amplifier. And finally, set the AUDIO PATH.
Setup 2
Stereo in, stereo out.
Setup 3
OUT A for guitar, OUT B for drum machine.
To get the best sounds, you can connect the Loop Core Stereo to a guitar amplifier and a full-range frequency amplifier. Set the AUDIO PATH as shown below. This will split the guitar signal and drum machine signal to OUT A & OUT B individually.
Setup 4
Both OUT A & B to a mixer.
When you are playing at home or in the studio with a mixer and/or PA system, you can connect the Loop Core Stereo to control the mix of your guitar and drum machine individually. Additionally, this setup includes a frequency compensation function to get a better signal from OUT A.
MIDI Control
Nearly every parameter of the Loop Core Stereo can be controlled by an external MIDI controller, such as tap tempo, stop/start/record, and so much more. The MIDI to 1/8” cable is included to get you started quickly.
*Please download the user’s manual and check the MIDI commands.
Customize your own Boot-up picture
The Loop Core Stereo allows users to customize their own boot-up picture with a GIF.
- Connect the Loop Core Stereo to your computer and download a GIF picture to the folder: NUX LOOPER >NUX_LOOP >GIF.
- Disconnect and reboot the Loop Core Stereo, and then enter the DISPLAY setting and set the BOOT-UP PICTURE option to USER.
- Reboot the Loop Core Stereo again. Enjoy your own customized GIF interface!
How to import playback to Loop Core Stereo?
When connecting a LOOP CORE STEREO to a computer, it will show “NUX LOOPER” as a USB flash disk. Click it, and you will see folder NCL-2. Click folder NCL-2 to enter, then you will see folder WAVE. Then you can drag the target wav file into the related folder. For example, if you want to put the playback wav file into phrase loop track 3, you can just drag your target wav file into folder W003. Then you are good to go.
Features
All new design with a high-definition color LCD display.
Up to 6 hours recording time(Stereo).
99 User memories.
Built-in rhythm tracks with 50 patterns.
Split out for two amplifiers.
Cab simulation for output to mixer.
Built-in MIDI control.
Sampling Rate: 44.1kHz.
A/D Converter: 24bit.
Signal Processing: 32bit floating.
Input: Mono/L/R.
Outputs: Mono/L/R/Phones
